1. Material: SS304

2. Surface treatment: high-brightness epoxy resin coating

3. Function: eye and face washing

4. Switch ball valve: two-piece quick-opening ball valve

5. Pipe diameter: 38mm

6. Nominal pressure: 1.0Mpa

7. Working pressure: 0.2~0.4Mpa

8. Test pressure: 1.5Mpa

9. Ambient temperature: 0 ~ 40℃

10. Eye/face wash water flow: > 11.4 L/min

11. Eye wash basin: 300mm straight edge design, water collection and concentration to prevent splashing

12. Dust cover: main body integrated design, not easy to lose

13. Water inlet size: 1/2" British external thread

14. Drain size: 1" British internal thread

15. Water inlet height: 753mm

16. Drain height: 86mm

17. After the eye and face wash is stopped, the water in the pipe is automatically drained to achieve the purpose of anti-freezing.

18. The sizes of the inlet and outlet can be customized according to user needs. It is recommended to install a maintenance emergency valve and filter at the inlet.
