1. Material: SS304

2. Product features: guardrail, large-size water collection tank (optional spray water curtain)

3. Surface treatment: fine polishing to enhance product corrosion resistance

4. Function: spray + eye wash (can be used simultaneously or separately)

5. Switch ball valve: two-piece quick-opening ball valve

6. Shower nozzle: spinning curling process design, diameter 250mm

7. Pipe diameter: 38mm

8. Nominal pressure: 1.0Mpa

9. Working pressure: 0.2~0.4Mpa

10. Test pressure: 1.5Mpa

11. Ambient temperature: 0℃~40℃

12. Spray water flow: ≥ 76L/min

13. Face/eye wash water flow: ≥ 11.4 Umin

14. Eye wash basin: 300mm Straight edge design, water collection and concentration to prevent splashing

15. Dust cover: integrated design of the main body, not easy to lose

16. Features of eyewash nozzle: patented design, with dual flow regulating valve

17. Water inlet size: 1" British internal thread

18. Drain size: 1" British internal thread

19. Water inlet height: 1305mm

20. Drain height: 206mm

21. Eyewash nozzle spacing: 170mm

22. Sump size: length x width x height = 1000x1000x120mm

23. The inlet and drain sizes can be customized according to user needs. It is recommended to set up maintenance emergency valves and filters at the water inlet; this product is a customized model, and the size and specifications of the sump can be customized according to the user's on-site environment needs.
