1. Material: SS304

2. Surface treatment: fine polishing to enhance the corrosion resistance of the product

3. Installation features: "Yun-style" pipe connection method is adopted, which can be quickly assembled and disassembled

4. Function: spray + eye wash + manual emptying

5. Suitable areas: low-cold areas

5. Switch ball valve: two-piece quick-opening ball valve + three-piece special ball valve

6. Shower nozzle: spinning curling process design, diameter 250mm

7. Pipeline diameter: 38mm

8. Eye wash basin: 300mm straight edge design, water collection and concentration to prevent splashing

9. Dust cover: integrated design of the main body, not easy to lose

10. Features of eye wash nozzle: patented design, with dual flow regulating valve

11. Water inlet size: 1" British external thread

12. Drain size: 1" British internal thread

13. Water inlet height: 810mm

14. Drain height: 86mm

15. Product features:

① Adopt a new patented eye wash nozzle. The water flow rate of the eyewash nozzle is controlled by the flow adjustment structure inside the nozzle. It has been debugged and corrected before leaving the factory. If the working pressure of the water source on site changes, it can be adjusted by itself;

② The main water inlet valve is a special three-way ball valve. The water inlet is open (press the three-way ball valve control handle downward 45° below the horizontal plane to open), and the drain port is closed: pull the three-way ball valve control handle upward (45° above the horizontal plane), the water inlet is closed, the drain port is opened, and the accumulated water in the pipeline is automatically drained.

③ The eyewash pipeline is equipped with a seepage hole to drain the accumulated water remaining in the eyewash nozzle, which is conducive to the cleanliness and antifreeze of the pipeline (part of the water is discharged into the sewer pipe from this hole during eyewashing, which does not affect the use effect.)

16. This eyewash has a manual emptying function and an antifreeze effect. It is suitable for use in areas with temperatures below 0℃ and in environments with hot water supply; the size of the inlet and outlet can be customized according to user needs. It is recommended to set a maintenance emergency valve and filter at the water inlet.
